Audio 630VDC PF-XAL-W-AL
Paper in Wax, Aluminium Foil
AMPOHM
Audio Capacitors are specially designed for
high performance audio systems, used in various applications.
These
paper in
wax (PIW) capacitors are hand wound using high purity aluminium foil
and have
their 1.0mm diameter tinned copper leads hand solder sealed to the
eyelets in
the end discs.
They
are wax impregnated before being assembled and hermetically
sealed in an aluminium housing with phenolic resin and rubber end
discs, all
being individually hand tested.
Caractéristiques
:
| Type: |
PF-XAL-W-AL |
| Capacitance: |
0.01µF – 10.0µF |
| Dissipation Factor : |
< 0.01@ 1KHz |
| Tolérance: |
+/- 20% up to 0.1µF |
| |
+/- 10% up to 5.0µF |
| |
+/- 5% above 5.0µF |
| Rated Voltage : |
630V DC |
| Temperature Range : |
-40 to +85C |
| Capacité (µF) |
D |
L |
| 0.01 - 0.05 |
15mm |
34mm |
| 0.05+ - 0.47 |
25mm |
54mm |
| 0.47+ - 1.2 |
35mm |
54mm |
| 1.2+ - 3.3 |
45mm |
95mm |
| 3.3+ - 10 |
65mm |
95mm |
|
